Seasonic 650W G12 V1.5 GM-650 Semi-Modular 80 PLUS Gold ATX PSU

Name: Seasonic 650W G12 V1.5 GM-650 Semi-Modular 80 PLUS Gold ATX PSU
Brand: Elegant Shopping eStore
SKU: V28-PSUSEAG12GM650
Price: 167.86 AUD
Availability: InStock

Sale price $167.86 AUD

Regular price ~~$248.95 AUD~~

https://elegantshop.com.au/products/seasonic-650w-g12-v1-5-gm-650-semi-modular-80-plus-gold-atx-psu

Quantity

Add to wishlist

Compare

Barcode: 4711173878490
Sku: V28-PSUSEAG12GM650
Collections: N/A

Description

G12 GM
The G12 GM Series is available in the standard ATX Form Factor and in wattages that are most common for a PC system. The Seasonic G12 GM-Series achieves 80 PLUS Gold standard, providing at least 87%, 90%, and 87% power usage efficiency at 20%, 50%, and 100% operating loads, respectively. This efficiency, combined with Active Power Factor Correction, enables the G12 GM series power supplies to reduce energy waste, resulting in savings on energy costs for users. Additionally, the G12 GM units utilize the LLC resonant converter design and the industry's leading Smart and Silent Fan Control (S2FC) for optimal performance and quiet operation.

SPECIFICATIONS

Technical Specifications
80PLUS		Gold
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		ATX/EPS
Dimensions		140 mm (L) x150 mm (W) x 86 mm (H)
Fan Information	Fan Size	120 mm
	Fan Control	Smart and Silent Fan Control
	Fan Bearing	Sleeve Bearing
	Life Expectancy	25,000 hours at 40 C, 15 % 65 % RH
Cable Information	Modularity	Semi-Modular
Cable Information	Cable type	Black Flat Cables
Electrical Features	Operating Temperature	0 - 50 C (derating from 100 % to 80 % from 40 C to 50 C linearly)
	MTBF @ 25 C, excl. fan	100,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, OCP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, CE, FCC
Safety and Environmental	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		5 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 8 - 4 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	20 A	20 A	54 A	0.3 A	2.5 A
		100 W		648 W	3.6 W	12.5 W
	Total continuous power	650 W
